Vanguard Engine Lathe

Description

Catilog Specs:
Model CW6263C
SERIAL .............................. GN08060816
MODEL ............................... CW6263C
SWING OVER WAYS ..................... 24.8"
SWING IN GAP .....31.5"
SWING OVER CROSS SLIDE .............. 14
DISTANCE BETWEEN CENTERS ............ 118.11"
SPINDLE SPEEDS ...................... 8.5 TO 800 RPM
DIAMETER OF HOLLOW SPINDLE HOLE ..... *** 5.11" ***
THREADS STANDARD .................... 1 TO TPI
THREADS METRIC ...................... 1 TO 240 MM
DIAMENTRAL THREADS .................. 1 TO 28 DP
CROSS FEEDS .........................
LONGITUDIANL FEEDS ..................
CHUCK 4 JAW ............ "
TAPER ATACHMENT ..................... YES
RAPID TRAVERSE 4 WAY ................ 150/75 IPM
THREAD DIAL ......................... YES
STEADY REST ROLLER TYPE ............. YES
2 AXIS DIGITAL READOUT NEWALL ....... YES
MOTOR ............................... 20 HORSEPOWER
